ANDONT 5 Stack Super Bright LED Andon Tower Lights with Buzzer, Red/Yellow/Green/Blue/White, Off-ON or Flash, Plug Play Ready

Name: ANDONT 5 Stack Super Bright LED Andon Tower Lights with Buzzer, Red/Yellow/Green/Blue/White, Off-ON or Flash, Plug Play Ready
Brand: ANDONT
SKU: B0FC264MM2
Price: 299.00 USD
Availability: InStock

$299.00 USD

~~$299.00 USD~~ $299.00 USD

Sale Sold out

Shipping calculated at checkout.

ANDONT 5 Stack LED Andon Tower Lights Workstation, 6 ft Reliable Green Industrial Adaptor, 16 ft extension cord, controhitel box. Ready to Install and Use - Industrials, Automotive, Real Estate, Business Products & Services, Information Technology, Consumer Products & Services, Agribusiness, Transportation & Logistics, Retail & Distribution, Warehouse, Workshop, Laboratory, Indoor Rated
Material: PC lens and ABS body and Aluminium Alloy Pole, 2.3622 in Diameter and 17.8 in Length Tower Stack Lights, Default Switch Settings: Red ON, Yellow ON, Green ON, Blue ON, White ON, 6 Red LEDs, 6 Yellow LEDs, 6 Green LEDs, 6 Blue LEDs, 6 Whinte LEDs, 9-Inch Aluminum Pole,16-ft extension cord, 2-Hole L-Bracket, Control Box, 6-ft 2 pole USA plug AC-DC Reliable Green Industial Adapter
18W wall-mounted style single-output green adaptor series.equipped with a 2-Pin standard USA AC power plug,adopting the input range from 85VAC-264VAC.With the extremely low no-load power consumption below 0.075w,compliant wit USA EISA 2007/DoE and Canada NRCan.The supreme feature allows the adaptor to save the energy when it is either under the operating mode or the standby mode. The utilise utilizes the 94V-0 flame retardant case, providing the double insulation that effectively prevents electrical shock. Certified for the international safety regulations.
Exquisite appearance with design patents, multiple functions, high cost performance. Adopt high brightness LED chip, wider angle, low thermal resistance, Color area concentrated, low brightness decay with a long life span. The whole structure design features good heat dissipation, high quality driver guarantees a long life time entirely. A reasonable layout of internal electronic components, strictly ensure a high efficient work state.
This is a Very Efficient Visual Communication Tool, Helps Improve Productivity and Saves You Time and Money

Product description

ANDONT — Visual Status Signaling for Smarter Production

ANDONT

Fully Assembled LED Andon Tower Stack Lights,has a 2 position industrial selector ABB switch to turn each light section to ON OFF .
The Buzzer Red Yellow Green Blue LED Tower Lights is connected to a control box with a 9 inch pole and right angle mounting bracket.
The 6 ft., equipped with a 2 Pin USA AC power plug,adopting the input range from 85VAC-264VAC.

Installation and use method:

Secure with two bolts, insert the power adapter into the 85V-264V socket and you are Ready & running.

Where to use:

Industrial, Automotive, Business Products & Services, Information Technology, Agribusiness, Real Estate, Consumer Products & Services, Retail & Distribution, Transportation & Logistics
Workshop, Workstation, Warehouse, Office, LAB, School.
This is a very efficient visual communication tool, Helps Improve Productivity and saves You time and Money!

Package Included:

60 mm/2.36 in diameter and 8.5 in Length Red Yellow Green Blue Buzzer Andon Lights
9 Inch aluminium pole & L shape bracket
16 ft Extension Cord
4 hole control box & ABB selector switch
MEAN WELL AC-DC Reliable Green Industrial Adaptor

Data sheet:

Power	1.2W for each color
Input voltage for module	DC24V
Input voltage for body	DC24V
Working Temperature	-20~45℃
Buzzer volume	high mode 85dB, low mode: 40dB

Material	PC lens and ABS body
Lifetime	50,000 hours
IP rating	IP53
Emitting angle	360°
Flash frequency	60-70/min

Turn the LED unit to unlock then raise upwards slowly

Unplug ribbon connector, remove module.

DIP

Plug ribbon connector.(slots of female plug towards outside)

Turn the body or LED unit to locked.

MEAN WELL AC-DC Reliable Green Industrial Adaptor

Featueres
FCC/UL/RoHS/CB/EAC Global certificates
Universal AC input/Full Range
2 pole USA pulg, Calss Ⅱ power unit
No load power consumption<0.075W
Energy efficiency Level VI
Protections: Short Circuit/Overload/Over voltage
Fully enclosed plastic case
Pass LPS

18W wall-mounted style single-output green adaptor series.equipped with a 2-Pin standard USA AC power plug,adopting the input range from 85VAC-264VAC.With the extremely low no-load power consumption below 0.075w,compliant with USA EISA 2007/DoE and Canada NRCan.The supreme feature allows the adaptor to save the energy when it is either under the operating mode or the standby mode. The utilise utilizes the 94V-0 flame retardant case, providing the double insulation that effectively prevents electrical shock. Certified for the international safety regulations.

Function set-up

DIP switch is in lamp body, unlock and remove the bottom LED module, then you can see the DIP switch.
Adjust DIP switch to set-up function you need.
Default DIP switch Settings: Buzzer/Red Flashing, Yellow Steady, Green Steady.
Buzzer Settings: No Buzzer/With Buzzer, Low/Normal sound, Intermittent sound/Continuous

	ANDONT 2-Stack LED Andon Tower Signal Light with Buzzer, Red/Green	ANDONT 3-Stack LED Andon Tower Signal Light with Buzzer, Red/Yellow/Green	ANDONT 4-Stack LED Andon Tower Signal Light with Buzzer, Red/Yellow/Green/Blue	ANDONT 5 Stack LED Andon Tower Lights with Buzzer, Red/Yellow/Green/White	ANDONT 3 Stack LED Andon Lights with Buzzer	ANDONT 4 Stack LED Andon Lights with Buzzer
						Buying Options
Customer Reviews	19	19	19	19	22	19
Price
Number of Lights	2	3	4	5	3	4
Flashing	Flashing	Flashing	Flashing	Flashing	Flashing	Flashing
Colour	Red,Green	Red,Yellow,Green	Red,Yellow,Green, Blue	Red,Green,Green,Blue,White	Red,Yellow,Green	Red,Yellow,Green,Blue
Buzzer	✓	✓	✓	✓	✓	✓
